What is the Maximum Distance for PoE? How Do You Extend PoE Distance?

Choosing-the-Best-Network-Switches-to-Extend-PoE-Distance-in-2023

The maximum PoE distance is 100 meters (328 ft). This is the maximum PoE cable length for UTP (Unshielded Twisted Pairs) cables that are utilized for PoE or any network data transmission.

We can overcome the PoE distance limit with PoE Extenders, PoE Media Converters, and PoE Fiber Switches. Using PoE Extenders will extend the PoE distance over UTP copper cables. By utilizing PoE Media Converters and PoE Fiber Switches, the fiber optic cabling will enable the distance extension beyond 100 meters, which depends on three things:

  • Fiber optic cable type
  • Data rate
  • The optical power of the equipment

Extend PoE Distance With PoE Extenders

When it comes to extending PoE distance, the first network device that comes to mind is PoE extenders. PoE extenders are unmanaged, which means they are plug-and-play with auto-negotiation and cannot accept any users' input or commands. PoE extenders can break through the limited distances of the Ethernet copper distance barrier, as they can be daisy-chained. PoE extenders use UTP copper cables that extend data and power beyond 100 meters.

  • Cost-effective distance extension and connectivity
  • External power is not available
  • External power is hard to provision
  • Replacing copper with fiber becomes cost-prohibitive

Commercial and Wide operating temperature PoE Extenders

Commercial PoE extenders come in two models with one RJ-45 PoE/PD port and one RJ-45 PoE/PSE or, and two RJ-45 PoE/PSE. IEEE 802.3at or HPoE 60W Power Sourcing Equipment such as an Ethernet switch or media converter will power PoE extenders, and they can power up to 60W PoE Powered Devices (PDs). This meets all types of IEEE standards: IEEE 802.3af/at (15.4W and 30W) and IEEE 802.3bt (60W and 100W). Omnitron PoE Extender operating temperatures come in 2 ranges: commercial (0 to +50ºC) and wide (-40 to +60ºC).
PoE extender with one RJ-45 PoE/PD port and up to two RJ-45 PoE/PSE ports

Industrial PoE Extenders

Industrial PoE extenders can operate at temperatures between -40ºC and 75ºC. Industrial PoE extenders are designed for harsh environments  and outdoor network applications, deployed in places with extreme cold or hot  environments.  RuggedNet PoE Extenders come in two models with one RJ-45 PoE/PD, and one RJ-45 PoE/PSE port, or two RJ-45 PoE/PSE ports.
Industrial PoE extender with one RJ-45 PoE/PD port and up to two RJ-45 PoE/PSE ports



Extend PoE Distance with PoE Media Converters

PoE media converters convert data transmitted on copper cables to fiber-optic cables and  vice-versa. PoE media converters have one or two RJ-45 ports (10/100/1000BASE-T) and one or two fiber ports (100BASE-X (SFP), 1000BASE-X (ST, SC, SFP), 1000BASE-BX (SC, SFP)). The fiber transmits only data and the copper ports provide power and data.

PoE Media Converters with one or two RJ-45 ports, and one or two fiber ports

Managed/Unmanaged

PoE Media Converters

 PoE types

Commercial /Industrial

Ports

Managed

PoE/

PoE+

Commercial

1 or 2 RJ-45 ports (10/100/1000BASE-T)

1 or 2 Fiber ports

(100BASE-X (SFP), 1000BASE-X (ST, SC, SFP), 1000BASE-BX (SC, SFP))

10/100/1000 Media Converter with Power over Ethernet (PoE or PoE+)

Unmanaged

PoE/

PoE+

Commercial

1 or 2 RJ-45 ports (10/100/1000BASE-T)

1 Fiber ports

(1000BASE-X (ST, SC, SFP), 1000BASE-BX (SC, SFP))

Unmanaged 10/100/1000 Media Converter with Power over Ethernet (PoE or PoE+)

Managed

PoE/

PoE+

Industrial

1 or 2 RJ-45 ports (10/100/1000BASE-T)

1 or 2 Fiber ports

(100BASE-X (SFP), 1000BASE-X (ST, SC, SFP), 1000BASE-BX (SC, SFP))

Industrial 10/100/1000 Media Converter with Power over Ethernet (PoE or PoE+)

Managed

PoE++/HPoE

Commercial

1 or 2 RJ-45 ports (10/100/1000BASE-T)

1 or 2 Fiber ports

(100BASE-X (SFP), 1000BASE-X (ST, SC, SFP), 1000BASE-BX (SC, SFP))

10/100/1000 Media Converter with Power over Ethernet (60W and 100W PoE)

Managed

PoE/

PoE+

Commercial

1 or 2 RJ-45 ports (10/100BASE-T)

1 or 2 Fiber ports

(100BASE-X (ST, SC, SFP),100BASE-BX (SC, SFP))

10/100 Media Converter with Power over Ethernet (PoE or PoE+)

Unmanaged

PoE/

PoE+

Commercial

1 or 2 RJ-45 ports (10/100BASE-T)

1 Fiber ports

(100BASE-X (ST, SC, SFP),100BASE-BX (SC, SFP))

Unmanaged 10/100 Media Converter with Power over Ethernet (PoE or PoE+)

Managed

PoE/

PoE+

Industrial

1 or 2 RJ-45 ports (10/100BASE-T)

1 or 2 Fiber ports

(100BASE-X (ST, SC, SFP),100BASE-BX (SC, SFP))

Industrial 10/100 Media Converter with Power over Ethernet (PoE or PoE+)



Extend PoE Distance with PoE Fiber Switches

PoE fiber switches have up to eight RJ-45 ports that support all the various PoE standards as defined by IEEE, which include IEEE 802.3af/at (15.4W and 30W) and IEEE 802.3bt (60W and 100W). There are one or two 1G fiber uplink ports supporting ST, SC, LC, and SFP transceivers and two 1G/10G uplink ports supporting SFP/SFP+ transceivers depending on the model type. With the help of these uplink ports, the distance extends up to 140 kilometers.



Commercial PoE Fiber Switches

Commercial PoE switches are typically used in an enterprise, operating at normal temperature, an Ideal product for deployment at schools, offices, and university campuses. These compact PoE fiber switches are available in managed models (10G/M, 10GPoE+/M and 10GPoEBT/M) and unmanaged models (10G/Sx, 10GPoE+/Sx and 10GPoEBT/Sx). The Omnitron PoE Fiber Switch operating temperatures come in 3 ranges: commercial (0 to +50ºC), wide (-40 to +60ºC), and extended (-40 to 75ºC).

PoE Fiber switch with two uplink ports and up to eight user ports



Managed /Unmanaged

PoE Switch

PoE types

Bandwidth

Ports

Managed

PoE/PoE+

10G

Four or eight 10/100/1000 RJ-45 PoE/PoE+user ports

Two 1/10G SFP/SFP+ transceiver uplink ports

Managed PoE Switch 6 and 10 Port PoE/PoE+ 10 Gigabit

Managed

PoE++/HPoE

10G

Four 10/100/1000 copper 60W or 100W PoE user ports

Two 1/10G SFP/SFP+ transceiver uplink ports

Managed PoE Switch 6 Port 60/100W IEEE 802.3bt 10 Gigabit

Managed

PoE/PoE+

1G

Four or eight 10/100/1000 copper PoE+ user ports

Two 10/100/1000 copper or Gigabit fiber uplink ports

Managed PoE Switch 6 and 10 Port PoE/PoE+ Gigabit

Managed

PoE++/HPoE

1G

Four 10/100/1000 copper PoE user ports

Two 10/100/1000 copper or Gigabit fiber uplink ports

Managed PoE Switch 6-Port 60/100W IEEE 802.3bt Gigabit

Unmanaged

PoE/PoE+

10G

Four or eight 10/100/1000 copper PoE/PoE+ user ports

Two 1/10G SFP/SFP+ transceiver uplink ports

Unmanaged PoE Switch 6 and 10 Port PoE/PoE+ 10 Gigabit

Unmanaged

PoE++/HPoE

10G

Four 10/100/1000 copper 60W or 100W PoE user ports

Two 1/10G SFP/SFP+ transceiver uplink ports

Unmanaged PoE Switch 6 Port 60/100W IEEE 802.3bt 10 Gigabit

Unmanaged

PoE/PoE+

1G

Four or eight 10/100/1000 copper PoE+ user ports

Two 10/100/1000 copper or Gigabit fiber uplink ports

Unmanaged PoE Switch 6 and 10 Port PoE/PoE+ Gigabit

Unmanaged

PoE++/HPoE

1G

Four 10/100/1000 copper PoE user ports

Two 10/100/1000 copper or Gigabit fiber uplink ports

Unmanaged PoE Switch 6-Port 60/100W IEEE 802.3bt Gigabit





Industrial PoE Fiber Switches

Industrial PoE switches can operate at temperatures between -40 ºC and 75 ºC. These ruggedized PoE fiber switches are designed for industrial and outdoor network applications powering Wi-Fi access points, small cells, IP surveillance cameras, and various industrial and transportation equipment. They are deployed in harsh and extreme environments. These compact industrial PoE switches are available as managed and unmanaged models.

 industrial PoE Fiber switch with two uplink ports and up to eight user ports



Managed /Unmanaged

Industrial PoE Switch

PoE types

Bandwidth

Ports

Managed

PoE/PoE+

10G

Four or eight 10/100/1000 copper PoE user ports

Two 1/10G SFP/SFP+ transceiver uplink ports

Managed Industrial PoE Switch 6 and 10 Port PoE/PoE+ 10 Gigabit

Managed

PoE++/HPoE

10G

Four 10/100/1000 copper PoE user ports

Two 1/10G SFP/SFP+ transceiver uplink ports

Managed Industrial PoE Switch 60/100W IEEE 802.3bt 10 Gigabit

Managed

PoE/PoE+

1G

Four or eight 10/100/1000 copper PoE+ user ports

Two 10/100/1000 copper or Gigabit fiber uplink ports

Managed Industrial PoE Switch 6 and 10 Port PoE/PoE+ Gigabit

Managed

PoE++/HPoE

1G

Four 10/100/1000 copper PoE user ports

Two 10/100/1000 copper or Gigabit fiber uplink ports

Managed Industrial PoE Switch 6-Port 60/100W IEEE 802.3bt Gigabit

Unmanaged

PoE/PoE+

10G

Four or eight 10/100/1000 copper PoE/PoE+ ports

Two 1/10G SFP/SFP+ transceiver uplink ports

Unmanaged Industrial PoE Switch 6 and 10 Port PoE/PoE+ 10 Gigabit

Unmanaged

PoE++/HPoE

10G

Four 10/100/1000 copper PoE ports

Two 1/10G SFP/SFP+ transceiver uplink ports

Unmanaged Industrial PoE Switch 60/100W IEEE 802.3bt 10Gigabit

Unmanaged

PoE/PoE+

1G

Four or eight 10/100/1000 copper PoE/PoE+ user ports

Fiber or copper uplink ports

Unmanaged Industrial PoE Switch 6 and 10 Port PoE/PoE+ Gigabit

Unmanaged

PoE++/HPoE

1G

Four 10/100/1000 copper PoE user ports

Two 10/100/1000 copper or Gigabit fiber uplink ports

Unmanaged Industrial PoE Switch 6-Port 60/100W IEEE 802.3bt Gigabit



Conclusion

The best network switch to extend the PoE distance between all three PoE media converters, PoE fiber switches, and PoE extenders is Omnitron compact PoE fiber switches. They have up to eight 10/100/1000 copper PoE user ports and two 1/10G SFP/SFP+ transceiver uplink ports, allowing you to connect more powered devices (PDs). Also, for industrial, telecom, utility, IoT, and transportation networks, the Omnitron Industrial PoE Fiber Switch is a perfect choice. If you are still unsure about which product should be your choice for powered devices (PDs), contact Omnitron Systems’ technicians to receive pre-sale support. We are available 24 hours a day, 7 days a week, and 365 days a year to answer your questions. Contact us today.
