Compact unpowered 1-Module Passive Chassis

iConverter® 1-Module Passive Chassis

fc2062aef352f80dc2215f346ba9ce28 XL
The iConverter 1-Module Passive Chassis is a one-slot, unpowered standalone chassis that can house all passive iConverter single slot modules. It is designed for network edge or Customer Premises deployments where unpowered, low-profile, low cost and flexible upgrades are important, making it an ide ...Read more

Features
  • Compact unpowered 1-Module Passive Chassis
  • Supports single slot passive iConverter CWDM/DWDM Multiplexers and OADMs
  • Wall-mount or tabletop options for flexible installations
  • DIN-rail, 19? and 23? rack mounting options available
  • Made in the USA
icons

  • Description
  • Features
  • Specifications
  • Ordering
  • Documents
  • Compact unpowered 1-Module Passive Chassis
  • Supports single slot passive iConverter CWDM/DWDM Multiplexers and OADMs
  • Wall-mount or tabletop options for flexible installations
  • DIN-rail, 19? and 23? rack mounting options available
  • Made in the USA
  • Lifetime Warranty and free 24/7 Technical Support
Model NumberDescription
8244-0
  1-Module Passive Chassis



Accessories
Model NumberDescription
8249-0
 Wall-Mount Hardware Kit
8260-0
 19” Rack-Mount Shelf
8260-2
 23” Rack-Mount Shelf
8250-0
 DIN Rail Mounting Kit

iConverter 1-Module Passive Chassis (Data Sheet)

iConverter 1-Module Passive Chassis (User Manual)

iConverter DIN Rail Wall Mounting Kit (User Manual)

The iConverter 1-Module Passive Chassis is a one-slot, unpowered standalone chassis that can house all passive iConverter single slot modules. It is designed for network edge or Customer Premises deployments where unpowered, low-profile, low cost and flexible upgrades are important, making it an ideal solution for Enterprise, datacenter and metro access interconnectivity.

Description 1-Module Passive Chassis
Model Number 8244-0
Module Capacity  1
Dimensions
W x D x H
3.8” x 5.5” x 1.0” (96.52 mm x 139.7 mm x 25.4 mm)
Weight
0.8 lbs. (361g)
Humidity 5 to 95% (non-condensing)
Altitude -100m to 4,000m
Warranty Lifetime warranty with 24/7/365 free Technical Support
