Managed 10 Gigabit Ethernet Switch

OmniConverter® 10G/M

OmniConverter 10G M 8x RJ-45
OmniConverter® 10G/M: 8 x 10/100/1Gbps RJ-45 No PoE to 2 x 1 Gbps / 10 Gbps, SFP, Fiber type depends on SFP, SFP-Dependent, Distance depends on SFP, Managed Ethernet Switch, Standalone/Wall-Mount, JPN 100-240VAC, Wide Temperature Range


Part Number

2900-0-28-8W

icons
Add to Quote

  • Description
  • Specifications
  • Documents

OmniConverter 10G/M (Data Sheet)

OmniConverter 10G/M (Quick Start)



OmniConverter Command Line Interface (User Manual)

OmniConverter Web Interface (User Manual)

OmniConverter / RuggedNet 2.5 Hierarchical CLI (User Manual)

OmniConverter® 10G/M: 8 x 10/100/1Gbps RJ-45 No PoE to 2 x 1 Gbps / 10 Gbps, SFP, Fiber type depends on SFP, SFP-Dependent, Distance depends on SFP, Managed Ethernet Switch, Standalone/Wall-Mount, JPN 100-240VAC, Wide Temperature Range

Specifications

Description OmniConverter® 10G/M
10/100/1000BASE-T with 1/10G Uplink Ports
Managed 6 and 10 Port 10Gigabit Ethernet Switch
Standard Compliances

IEEE 802.3, IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1ab, IEEE 802.1ax, IEEE 802.1w RSTP/MSTP

RFC 5424, RFC 4541, RFC 2710, IEC 624339-2, SMTP, SNTP, RADIUS, TACACS+, IEEE 802.1x
Regulatory Compliances
(*Pending)

Safety*: UL 62368-1, UL 60950-1,

              IEC 62368-1, IEC 60950-1,

              EN 62368-1, EN 60950-1,

              CAN/CSA C22.2 No. 62368-1-14, CAN/CSA C22.2 No. 60950-1,

              CE Mark,

              UKCA

EMC:     EN 55032/24 CE Emissions/Immunity,

              IEC 61000-6-4 Industrial Emissions, IEC 61000-6-2 Industrial Immunity

EMI:      CISPR 32,

              FCC 47 Part 15 Subpart B Class A

EMS:     IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV,

              IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m,

              IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV (DC models),

              IEC 61000-4-4 EFT: Power: 1 kV; Signal: 1 kV (AC models),

              IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV (DC models),

              IEC 61000-4-5 Surge: Power: 1 kV Line/Line; 2 kV Line/Gnd; Signal: 2 kV (AC models),

              IEC 61000-4-6 CS: Signal: 10 V, IEC 61000-4-8 (Magnetic Field) 30A/m,

              IEC 61000-4-11 (Voltage Dips, interrupts)

IP Rating: IP20 Protection

ACT: TAA, BAA,NDAA
Environmental REACH, RoHS and WEEE
Management

IPv4 and IPv6 address

Web, Telnet, SSH, SNMPv1/v2c/v3

In-Band management via Ethernet port

Out-of-band management via serial port
Frame Size Up to 10,240 bytes
Port Types

Copper:       10/100/1000BASE-T (RJ-45)

SFP/SFP+: 10GBASE-X Fiber Transceivers

                   10GBASE-T Copper Transceivers

                   1000BASE-X Fiber Transceivers

                   1000BASE-T Copper Transceivers

                   10/100/1000BASE-T SGMII Copper Transceivers

Serial:         RS-232 (RJ-45)
Cable Types

Copper: EIA/TIA 568A/B, Cat 5 UTP and higher

Fiber:     Multimode: 50/125, 62.5/125µm

              Single-mode: 9/125µm

Serial:    Category 3 and higher
AC Power Requirements
(Models with AC/DC Adapters)

100 - 240VAC/50 - 60Hz

0.25A max at 115VAC

0.12A max at 230VAC
DC Power Requirements
(Models with DC Terminals)

4 RJ-45 Ports:

+12 to +57VDC;

0.81A @ 12VDC

0.20A @ 48VDC

2 Pin Terminal (isolated)

8 RJ-45 Ports:

+12 to +57VDC;

0.90A @ 12VDC

0.22A @ 48VDC

2 Pin Terminal (isolated)
Dimensions
(W x D x H)		 6.28” x 5.2” x 1.5” (159.5 mm x 132.1 mm x 38.1 mm)
Weight

4 RJ-45 Ports:

Module Only: 1.5 lb. (720 grams)

Module with AC/DC Adapter: 2.0 lbs. (913 grams)

8 RJ-45 Ports:

Module Only: 1.6 lbs. (748 grams)

Module with AC/DC Adapter: 2.1 lbs. (941 grams)
Operating Temperature Commercial: 0 to 50°C
Wide: -40 to 60°C (-20°C AC cold start)
Extended: -40 to 75°C (-20°C AC cold start)
Storage: -40 to 80°C
Humidity 5% to 95% (non-condensing)
Altitude -100m to 4,000m (operational)
MTBF (hrs) Module Only: 290,000
AC/DC Adapter: 100,000
Warranty 5 year product warranty with 24/7/365 free Technical Support
2 year AC power adapter warranty
