Expand Fiber Capacity with CWDM Multiplexers

Coarse Wavelength Division Multiplexing (CWDM) increases the capacity of SONET/SDH, metropolitan, first-mile access, mobile backhaul and hybrid coax/fiber networks to enable new services and revenues. Each CWDM wavelength is an independent data channel that can transport a different protocol (Ethernet, TDM, etc.) and data rate (up to 10 gigabits each).

• Co-locate more Service Providers at cellular towers
• Overlay Ethernet and TDM circuits onto SONET rings
• Add new subscribers to fiber access networks and hybrid coax/fiber networks

Case Study: CWDM over SONET Ring
CWDM Point-to-Point Application Example
CWDM Bus (Daisy Chain) Add and Drop Application Example
CWDM over SONET Application Example

Visit the CWDM Resource Center to view videos and download white papers

iConverter CWDM/X and CWDM/AD Add+Drop MUX products multiplex up to sixteen independent wavelengths over single mode fiber.

iConverter CWDM modules utilize a small and scalable plug-in form factor, and can be installed in any powered or unpowered iConverter chassis achieving some of the highest port densities in the industry. iConverter CWDM modules are available in expandable four-channel and eight-channel configurations.

The modules are designed to be integrated with other iConverter media converters and transponders to provide a true multi-service platform capable of delivering Ethernet, TDM, SONET and other services across a CWDM common link.

Learn more about iConverter CWDM Multiplexers

Learn more about Omnitron CWDM Pluggable Transceivers

Extend the Distance of Ethernet, SONET and Optical Transport Network Links

Protocol Transparent Media Converters/Transponders

iConverter protocol transparent media converters/transponders provide conversion between different wavelengths, multimode and single-mode, and dual and single-fiber. They function as repeaters that amplify optical signals and support the three Rs (regeneration, retiming and reshaping). iConverter media converters/transponders support Omnitron and third-party pluggable transceivers.

The iConverter xFF Transponder is an SFP to SFP protocol-transparent fiber converter that supports data rates from 1Mbps to 4.25Gbp. The xFF provides distance extension and CWDM wavelength conversion for Ethernet, Fast Ethernet, Gigabit Ethernet, SONET (OC-3/12/48), SDH (STM-1/4/16) and 1x/2x/4x Fibre Channel applications.

The iConverter XG and XG+ are 10G transponders that support any combination SFP+ and XFP (fiber and CX4 copper) transceivers, and data rates of 9.95Gbps to 11.32Gbps. The XG and XG+ transponders provide distance extension and wavelength conversion for 10G Ethernet, 10G SONET/SDH, 10G Fibre Channel and 10G OTN (G.709).

OTN Long-Haul DWDM Application

This application shows three 10G OTN connections across a DWDM network. Three iConverter XG+ modules with high-power XFPs are installed in a 5-Module Chassis and connected with fiber patch cables to a DWDM Multiplexer. The iConverter XG+ modules function as fiber repeaters and wavelength transponders. The high-power XFPs installed in the XG+ perform Forward Error Correction on the incoming signal, then amplify and re-encapsulate the outbound OTN signal.

iConverter Single-mode to Multimode Fiber Converters

iConverter fiber-to-fiber media converter modules provide distance extension with single fiber to dual fiber and single-mode to multimode fiber conversion. Select iConverter modules support VLAN switching capabilities and iConverter fiber-to-fiber Network Interface Devices (NIDs) feature integrated management and carrier-grade fault detection capabilities.

View a Multimode Fiber to Single-mode Fiber Application Example

View a Dual Fiber to Single Fiber Application Example

Extend the Distance of SONET Networks

OC-3/STM-1 and OC-12/STM-4 fiber-to-fiber media converters extend SONET fiber distances by amplifying the optical power, converting single mode to multi-mode, and dual fiber to single-fiber, and converting wavelengths.

OC-3/STM-1 and OC-12/STM-4 Fiber Extension Application Example

OC-3/STM-1 and OC-12/STM-4 SONET Ring Distance Extension Application Example

Learn more about iConverter TDM Media Converters

Reach More Customers with Demarcation Extension and Riser Management

The iConverter Multi-Service Platform enables fiber connectivity between Service Provider demarcation equipment and tenants in hi-rise buildings and business complexes.

In this Riser Management application example, Ethernet and T1 services are delivered via fiber links to tenants in the building from Service Provider equipment with copper interfaces on the ground floor.

View this Riser Management Application Example

iConverter Network Interface Devices and managed media converters enable fiber connectivity for Ethernet, T1/E1 and T3/E3 demarcation extension in hi-rise buildings and business complexes.

iConverter Ethernet Copper-to-Fiber media converters

iConverter TDM copper-to-fiber media converters extend T1/E1, T3/E3/DS3, and OC-3/STM-1 copper services over fiber.

iConverter TDM media converters

The iConverter platform is available with high-density chassis for distributing multiple fiber runs from the demarcation point, and standalone modules to hand off services at the tenant offices.

Multiple services can be transported over an existing fiber link with iConverter CWDM multiplexers and T1/E1 multiplexers. Preserve investments and save the cost of installing new fiber links by expanding the capacity of existing fiber infrastructure.
